Optical System |
Infinite Optical System |
|
Viewing Head |
Seidentopf Binocular Viewing Head, Inclined at 45°, 360° Rotatable, Interpupillary 48-75mm |
|
Eyepiece |
Wide Field Eyepiece WF10X/20, Eyepiece Tube Diameter 30mm |
|
Wide Field Eyepiece WF15X/16 |
||
Wide Field Eyepiece WF20X/12 |
||
Objective |
LWD Infinite Plan Achromatic Objective 4X/0.10 WD=22 |
|
LWD Infinite Plan Achromatic Phase Objective |
10X/0.25 WD=6 |
|
20X/0.4 WD=3.1 |
||
40X/0.55 WD=2.2 |
||
High-level Phase Contrast Objective |
10X/0.25 WD=6 |
|
20X/0.4 WD=3.1 |
||
40X/0.55 WD=2.2 |
||
Nosepiece |
Backward Quintuple Nosepiece |
|
Condenser |
ELWD Condenser NA0.3,LWD72mm(without Condenser 150mm) |
|
Centering Telescope |
Centering Telescope(Φ30mm) |
|
Phase Annulus |
10X、20X、40X Phase Annulus Plate(Adjustable) |
|
Stage |
Plain Stage 230X170mm |
|
Glasse Insert |
||
Attachable Mechanical Stage,X、Y Coaxial Control,Moving Rang 80X120mm |
||
Auxiliary Stage |
||
Terasaki Holder |
||
Petri Dish HolderΦ38 |
||
Petri Dish HolderΦ54 |
||
Focusing System |
Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Moving Range up 4.5mm down 4.5mm |
|
Illumination |
6V30W Halogen Lamp, Brightness Adjustable |
|
Filter |
Blue、Green and Ground Glass, Diameter 45mm |
|
Accessories |
Photo Attachment |
|
C Mount 0.4X |
||
Epi-Fluorescent Attachment |
||
Modulation Contrast |
