Excellent fluroscent image with infinitive optical system.
LED illumination with 50,000 hours life expectancy.
No need for cooling system and protection device due to LED cold light source.
465-475nm excited wavelength with high snr.
Convenient to use, no need warm-up.
More fluorescent filters are available for different applications.
|
Optical System |
Infinite optical system |
||||
|
Viewing Head |
Compensation free binocular head inclined at 30°, interpupillary 48-75mm |
||||
|
Eyepiece |
WF10X/18 |
||||
|
Nosepiece |
Backward quadruple nosepiece |
||||
|
Infinite Objective |
Semi-plan Achromatic Objective |
4X |
|||
|
10X |
|||||
|
20X |
|||||
|
40X |
|||||
|
100X |
|||||
|
Fluorescent Objective |
4X, 10X, 20X, 40X, 100X |
||||
|
Condenser |
Condenser NA 1.25 |
||||
|
Focusing |
Coaxial coarse & fine adjustment, Fine division 0.002mm |
||||
|
Stage |
Double layers mechanical stage140X140/75X50 |
||||
|
Photo Attachment |
|
||||
|
Video Adapter |
|
||||
|
Illumination |
S-LED Illumination, Brightness Adjustable |
||||
|
Halogen lamp 6V/20W |
|||||
|
Reflected Light Source |
|
Excitation |
Dichroic Mirror |
Barrier Filter |
|
|
Blue Excitation |
BP460～490 |
DM505 |
BA515 |
||
|
Green Excitation |
BP510～550 |
DM570 |
BA590 |
||
|
Lamp |
3W LED (465-475nm) |
||||
|
3W LED (525-530nm) |
|||||
|
Immersion Oil |
Fluorescent free oil |
||||
