Unrivaled optical performance with infinity parallel optical system.
Providing even illumination and 6000 hours life expectancy with ultra-thin LED illumination for both incident and transmitted light.
With complete accessories, it can be used widely for scientific research, industry, biological and medical field.
|
Optical System |
Parallel optical zoom system |
|
|
Viewing Head |
Binocular head, 20°inclined,Interpupilary distangce 55-75mm |
|
|
Tilting binocular eyepiece tube, 0-35°inclined, Interpupilary distangce 55-75mm |
||
|
Eyepiece |
WF10X/Φ22 |
|
|
WF10X/Φ24 |
||
|
WF15X/Φ16 |
||
|
WF20X/Φ12 |
||
|
WF30X/Φ8 |
||
|
Objective
|
Zoom Objective |
0.8X～5X |
| 0.8X～6.4X | ||
|
0.8X～8X |
||
|
Objective |
1X Plan achromatic objective WD：78mm |
|
|
0.5X Achromatic objective WD：186mm |
||
|
2X Plan achromatic objective WD：32.5mm |
||
|
0.5X Plan apochromatic objective |
||
|
Zoom Ratio |
1: 6 | |
| 1: 8 | ||
|
1:10 |
||
|
Working Distance |
78mm |
|
|
Focusing Range |
105mm |
|
|
Illumination |
Transmission & reflection LED illumination, brightness adjustable |
|
|
Optional |
Coaxial illumination |
|
|
Epi-fluorescent attachment |
||
|
Dark field attachment |
||
|
Simple polarization set |
||
|
Iris diaphragm |
||
|
Beamsplitter（one port） |
||
|
eamsplitter（two ports） |
||
|
Photography & video attachment |
||
|
Moveable stage |
||
|
Temperature controlled stage |
||
|
Universal table stand/Table clamp stand |
||
|
Coaxial coarse & fine focusing unit |
||
|
Cold light illumination with dual light guide |
||
|
LCD Attachment |
||
